Details:

Summit Commercially Approved, ADA Compliant, ENERGY STAR Certified Outdoor All-Refrigerator for Built-In or Freestanding Use with a Shallow 17.25" Depth, Stainless Steel Door, and Front Lock / SPR196OSADA

Summit's line of outdoor appliances includes slim-fitting, ADA compliant display beverage centers designed for optimum product storage.

The SPR196OSADA features a versatile design that meets NSF-7 and UL-471 commercial standards but is also approved for residential use. Sized at just 19 inches wide and 17.25 inches deep, it features a jet black cabinet with a sealed back for safe installation outdoors and protection from the elements. The user-reversible stainless steel door adds durability and elegance to any outdoor setting and the stainless steel pro-style handle completes the look. A factory-installed lock keeps contents secure, while a right-angle plug and integrated hinge provide added flexibility in placing the unit. Two leveling legs keep the unit level on uneven surfaces.

Inside, the SPR196OSADA utilizes an internal fan to ensure the unit is evenly cooled from top to bottom. An automatic defrost system ensures minimal user maintenance, while LED lighting allows full visibility of stored items in the jet black interior. Three adjustable slide-out glass shelves with six placement positions provide flexible storage capacity inside the 3.1 cu. ft. interior. A shelving brake system offers added safety when moving and storing contents, while two chrome door racks are ideal for storing condiments, canned beverages, and other larger items. The dial thermostat, with seven temperature settings, is located in the front upper-right corner for easy temperature management.

The SPR196OSADA is sized at 32.5 inches high to fit under most lower ADA compliant counters. This unit can be used built-in or freestanding in indoor or outdoor settings. For a similar unit with a glass door, see the SPR489OSADA.



FEATURES:

100% CFC free - Environmentally friendly design does not contain ozone-damaging chemicals Factory installed lock - Keyed lock offers added security, with two keys included
17.25" shallow depth - Ideal for home wet bars, island kitchens, and other applications with limited footprint space Fully finished black cabinet - Allows the unit to be used freestanding
ADA compatible height - Sized at 32.5" high for installation under most lower ADA compliant counters LED lighting - Automatically illuminates when the door is open for an attractive and energy efficient view
Adjustable shelves - Three glass shelves with brake system ensures safe, optimal storage Professional handle - Stainless steel handle adds an attractive touch
Adjustable thermostat - Dial thermostat with seven temperature settings offers easy temperature management Reversible door - User-reversible door swing makes it easy to adjust to your setting as needed
Automatic defrost - Reduced user maintenance with auto defrost system Right-angle plug - Provides flexibility in unit placement without needing added depth
Black interior finish - Allows for easy cleaning and organization within the interior of the unit Sealed back - Space saving design with easier cleanability and added protection from the elements
CARB Compliant - Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations Stainless steel door - Stainless steel door affords added durability
Commercially approved - ETL-S listed to NSF-7 standard and meets UL-471 for use in commercial settings Versatile construction - Versatile design allows for residential use
Door racks - Two chrome racks accommodate a variety of sizes for optimal interior storage Weatherproof design - Approved for use in the outdoors with a stainless steel door for added durability
ENERGY STAR certified - Rated by the DOE to perform with more efficiency than federal standards require, saving your unit energy and you on higher utility costs

SPECIFICATIONS:

Overview

Height of Cabinet 32.5" (83 cm)
Width 19.0" (48 cm)
Depth 17.25" (44 cm)
Depth with Handle 19.0" (48 cm)
Depth with door at 90° 35.0" (89 cm)
Capacity 3.13 cu.ft. (89 L)
Defrost Type Automatic
Door Stainless Steel
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Energy Usage/Year 259.0kWh/year
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 70.0 lbs. (32 kg)
Shipping Weight 75.0 lbs. (34 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101068183


Refrigerator Features

Door Swing RHD
Reversible Yes
Shelf Type Glass
Shelf Qty 3
Adjustable Shelves Yes
Thermostat Type Dial
Fan Type Interior
Refrigerant Type R600a
Refrigerant Amount 0.88oz.
High Side PSI 320
Low Side PSI 120
Level Legs Qty 2
Interior Light Yes
Temperature Range 34 to 50ºF
Sound Level 33.4 dB



Dimensions

Interior Height 29.0" (74 cm)
Interior Width 16.0" (41 cm)
Interior Depth 12.75" (32 cm)
Compressor Step Height 7.0" (18 cm)
Compressor Step Width 16.0" (41 cm)
Compressor Step Depth 6.25" (16 cm)




AVAILABLE UPGRADES:

Exterior

Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles
LHD - Left hand door swing Door reversal to left hand swing
Extra key Extra keys available for purchase
ODA - Open door alarm Add an open door alarm to audibly buzz when the door is left ajar.

OTHER AVAILABLE MODEL:



SPR196OS24

24" Wide Outdoor All-Refrigerator for Built-In or Freestanding Use with a Shallow 17.25" Depth, Slide-Out Storage Compartment, Stainless Steel Exterior, Outdoor Cover, and Front Lock

SPR196OS

Commercially Approved, ENERGY STAR Certified Outdoor All-Refrigerator for Built-In or Freestanding Use with a Shallow 17.25" Depth, Stainless Steel Door, and Front Lock

SPR196OSCSS

Commercially Approved, ENERGY STAR Certified Outdoor All-Refrigerator for Built-In or Freestanding Use with a Shallow 17.25" Depth, Stainless Steel Door and Cabinet, and Front Lock


RESOURCES:

BROCHURE
USE & CARE
TECHNICAL DRAWING
ENERGY GUIDE
